How do I use MDT with PowerShell scripts?

by · Published · Updated

Applies to: Microsoft Deployment Toolkit (MDT) 8456 and later
Last updated: May 2025

Problem

You want to enhance or customize MDT deployments by running PowerShell scripts—either to set variables, configure Windows, collect logs, or perform custom post-deployment tasks.

Solution

MDT supports running PowerShell scripts as part of Task Sequences or during deployment via command-line steps. Scripts can be run at any stage, and MDT exposes useful environment variables to PowerShell.

Step-by-Step Guide

1. Prepare Your PowerShell Script

Create a .ps1 script with your desired logic. Example: Set-RegistrySettings.ps1:

Set-ItemProperty -Path "HKLM:\Software\Contoso" -Name "SupportContact" -Value "IT Dept"

Save the script in the MDT Scripts folder:

<DeploymentShare>\Scripts\

2. Add the Script to the Task Sequence

  • Open Deployment Workbench
  • Go to Task Sequences > Right-click your Task Sequence > Properties
  • Select the Task Sequence tab

Step to Add:

  • Click Add > General > Run PowerShell Script
  • Set:
    • Name: e.g., Configure Registry Settings
    • Command line: powershell.exe -ExecutionPolicy Bypass -File "%SCRIPTROOT%\Set-RegistrySettings.ps1"

%SCRIPTROOT% automatically resolves to the MDT Scripts folder during deployment.

3. Access MDT Variables in PowerShell (Optional)

MDT variables are exposed via the ZTIUtility COM object:

$TS = New-Object -ComObject Microsoft.SMS.TSEnvironment
$ComputerName = $TS.Value("OSDComputerName")

You can also set variables dynamically:

$TS.Value("CustomVar") = "Value123"

4. Conditional Execution (Optional)

Add conditions under the Options tab of the step:

  • Based on computer model, location, role, or variable value
  • Example:
    • Run script only on laptops:
      SELECT * FROM Win32_Battery

Use Cases for PowerShell in MDT

  • Rename computers using complex naming logic
  • Log deployment details to a server
  • Add custom registry keys or certificates
  • Install software not supported natively in MDT
  • Set environment or domain policies post-deployment
  • Copy post-install files or drivers

Notes

  • Always test scripts independently before adding them to MDT
  • Use Write-Output or Out-File to create custom logs
  • PowerShell logs can be found under:
    • C:\MININT\SMSOSD\OSDLOGS\
    • Or redirected to a custom folder using your script
